- Brand
- Sick
- Cable Length
- 0.5 m
- Series
- DBS36
- Pulses Per Revolution
- 1,200
- Maximum Revolutions
- 6,000 min⁻¹
- Output Signal Type
- TTL / RS-422
- Shaft Diameter
- 6 mmWith flat
- Supply Voltage
- 4.5 ... 5.5 V
ParameterValue
- Resolution
- 90°, electric/pulses per revolution
- IP Rating
- IP65
- Minimum Operating Temperature
- -20 °C
- Maximum Operating Temperature
- +95 °C
- Mounting Type
- Solid Shaft, Face Mount Flange
- Connection Type
- Cable, 8-wire, with male connector, M12, 8-pin, universal, 0.5 m
- Current Rating
- ≤ 30 mA
- Switching Frequency
- ≤ 300 kHz
ParameterValue
