Infineon MOSFETs IPW60R170CFD7XKSA1

Infineon, This is manufactured by Infineon Technologies. The manufacturer part number is IPW60R170CFD7XKSA1. It is assigned with possible HTSUS value of 8541.29.0095. The typical Vgs (th) (max) of the product is 4.5v @ 300 µa. The product has -55 °c ~ 150 °c (tj) operating temperature range. Moreover, the product comes in to-247-3. It has a maximum Rds On and voltage of 170mohm @ 6a, 10v. The maximum gate charge and given voltages include 28 nc @ 10 v. The product is rohs3 compliant. In addition, it is reach unaffected. It carries FET type n-channel. The drive voltage (maximum and minimum Rds On) of the product includes 10v. It is shipped in tube package . The product has a 650 v drain to source voltage. The maximum Vgs rate is ±20v. Its typical moisture sensitivity level is 1 (unlimited). The product carries maximum power dissipation 75w (tc). The products input capacitance at maximum includes 1199 pf @ 400 v. The product is available in through hole configuration. The product coolmos cfd7, is a highly preferred choice for users. pg-to247-3-21 is the supplier device package value. The continuous current drain at 25 °C is 14a (tc). This product use mosfet (metal oxide) technology. Moreover, it corresponds to ipw60r170, a base product number of the product. The product is designated with the ear99 code number.
